SIEMENS
LR97CAQ50
IQ500 90CM CEILING EXTRACTOR STAINLESS STEEL
Technical Overview
Color body
Stainless steel
Material body
Stainless steel
Design
Built-in
Number of speed settings
3-stage + 2 intensive
Max. air extraction
459 m³/h
Boost position air extraction
798 m³/h
Sound power at max. speed (2010/30/EC)
56 dB
Width
90 cm
Width of the appliance
900 mm
Depth
500 mm
Minimum distance above an electric hob
650 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
150 mm
No-return airflow flap
No
Length electrical supply cord
130.0 cm
Net weight
27.2 kg
Minimum width for installation
888 mm
Maximum width for installation
888 mm
Depth for installation
487 mm
